PRODUCT DESCRIPTION
Fits: 1966-69 Dodge/Plymouth, B-Body (22" Core)
Champion Core 4-Row
RADIATOR FLOW: DOWN FLOW
CORE DIM 17-1/2" (H) x 22" (W)
OVERALL 23-3/4" (H) x 26" (W)
HOSE LOCATIONS: IN: Off-Set Driver / OUT: Driver
HOSE FITTINGS: IN: 1 1/2 - OUT: 1 1/2
TRANS COOLER: 1/8-27NPT
MOUNTING TYPE: BRACKET MOUNT
Champion Cooling System Monster Core Radiators have four rows of 5/8 in. tubes. with a cooling capacity to approximately 800-1200+ horsepower. Each radiator is manufactured to the highest standards and craftsmanship at an ISO-certified facility. All Champion Radiators are built with 100% welded seams with brazed-core technology and absolutely no epoxy.
Features
•All-Aluminum Design with 4 Rows of 5/8 in. Tubing
•Welded Seams Brazed Core Technology (No epoxy)
•Approximately 800 to 1200+ Horsepower Cooling Capacity
•Standard Radiator Cap Included
